Vertiv Avocent LV5520 High-Performance KVM Extender | Receiver
Login to View Prices
The Vertiv Avocent LongView 5520 Receiver (LV5520R) is the latest in the Avocent high-performance KVM Extender family of products. Coupled with the Avocent LV5520T, the LV5520R is a point-to-point high performance KVM extender that provides 24-bit color graphics over a single head up to 4K@60Hz. Along with providing real-time access, high-speed USB 2.0 emulation, and HD analog audio, the LV5520R provides an effortless and automatic connection over the IP network without needing extensive manual setup. Increase business security with signed upgrade files and firmware updates from a single USB flash drive. The LV5520R is ideal for users in broadcasting, control centers, and other industries requiring high performance, 4K video.
- Delivers seamless KVM control and 4k video transmission.
- Allows for greater distance with the Fiber Option.
- Provides ultra-high-resolution video images for single-monitor and high-res video for dual-head.
- Plug-and-play with no drivers or software to install, and no on-site configuration required.
- Faster throughput with updated USB.
Additional information
| Number of HDMI Ports | 0 |
|---|---|
| Maximum Operating Distance | 13123.36 ft |
| Number of Network (RJ-45) P | 1 |
| Connectivity Technology | Wired |
| Number of Computers Support | 1 |
| Graphic Mode | 4K |
| Number of Local Users Suppo | 1 |
| Number of USB Ports | 2 |
| Product Model | LV5520R |
| Package Contents | <ul> <li>LV5520 High-Performance KVM Extender, Receiver</li> <li>1 x LV5500 Extender Quick Installation Guide</li> <li>1 x Extender RMK Quick Installation Guide</li> <li>1 x Compliance/Safety Sheet (See PLM BOM) 1 each</li> <li>1 x Customer Support/Warranty Card (See PLM BOM)</li> <li>1 x 3.5mm stereo plug to plug audio cable, 3meter </li> <li>2 x USB cable, Type A to Type B, 1.8meter</li> <li>2 x DisplayPort cable, M-M, High Bit-Rate, 2meter </li> <li>1 x Power supply: HK-AB-050A400-D56 or HK-25-AB-050A400-D56 </li> <li>1 x China RoHS Declaration</li> <li>1 x Vertiv document wallet </li> </ul> |
| Maximum Video Resolution | 4096 x 2160 |
| Platform Supported | PC,Mac,Unix,Sun,Linux |
| Power Consumption | 18 W |
| Input Voltage | 120 V AC,230 V AC |
| USB | Yes |
| Product Series | 5000 |
| Device Type | High Performance KVM |
| HDMI | No |
| Number of PS/2 Ports | 0 |
| Number of VGA Ports | 0 |
| Number of DVI Ports | 0 |
| PS/2 Port | No |
| Headphone | Yes |
| KVM Technology | Digital |
| Product Type | KVM Extender Receiver |
| Number of Remote Users Supp | 0 |
| DVI | No |
| Manufacturer Website Addres | |
| Manufacturer | Vertiv |
| VGA | No |
| DisplayPort | Yes |
| Product Line | LongView |
| Network (RJ-45) | Yes |
| Country of Origin | United Kingdom |
| Receiver Width | 7.32" |
| Receiver Weight (Approximat | 2.73 lb |
| Receiver Depth | 5.83" |
| Receiver Height | 1.54" |
| Proprietary Interface | No |
| Microphone | Yes |
| TAA Compliant | Yes |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Limited Warranty | 2 Year |
| Packaged Quantity | 1 |
| Environmentally Friendly | Yes |
| Input Voltage Range | 100-240 VAC |
| Product Color | Black |
| UPC | 636430090924 |
| MPN | LV5520R-400 |
| Brand | AVOCENT |
