Eaton Tripp Lite Series SmartPro 1440VA 1440W 120V Line-Interactive Sine Wave UPS – 8 Outlets, Extended Run, Network Card Option, LCD, USB, DB9, 2U Rack/Tower – Battery Backup

Login to View Prices

9 in stock

SKU: IMSJR6581 Categories: ,

1.44kVA/1.44kW/120V Battery Backup for Distributed IT, Telecom or Enterprise Deployments
This rack-mount line-interactive UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage your valuable IT equipment or destroy data. The SMART1500RMXL2U is ideal power management for high-end in-rack networking equipment, including servers, VoIP phones, data storage and PoE switches. Unity power factor ensures the most watts possible at each power rating, so you can connect more equipment.

Reliable, Expandable Battery Backup Keeps You Operational Through Power Outages
The field-replaceable, hot-swappable VRLA battery modules allow you to work through short power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout. Switchover from line to battery power happens within milliseconds to maintain continuous operation of connected equipment without interruption or rebooting. Extra runtime is available by connecting up to four optional extended battery modules (BP48VRM2U, sold separately).

Optional LX Platform Network Management Card Allows Remote Access 24/7
The WEBCARDLXE network interface (sold separately) enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. The IP-based Auto Probe feature ensures continuous network uptime by communicating with other network devices, detecting lost connectivity and automatically rebooting IT equipment. Optional EnviroSense2 modules (E2MT, E2MTDO and E2MTHDI, all sold separately) provide a variety of environmental monitoring and control options.

NEMA 5-15R Outlets Protect Your Connected Components
Eight managed 5-15R outlets provide connected equipment with pure sine wave AC output and allow you to monitor power consumption down to the outlet group level. Power provided by these outlets is filtered to protect connected equipment against damaging surges and line noise. Four outlets are grouped into two programmable load banks that let you shed non-critical loads to extend runtime for critical loads. Front and rear cooling fans help protect equipment from overheating.

Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts. The SMART1500RMXL2U maintains regulated 120V nominal output during brownouts and overvoltages from 80V to 151V while keeping the battery fully charged and ready to take over in case of power failure.

Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better
This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer.

ENERGY STAR-Certified to Help You Save Money and Protect the Environment
By meeting strict U.S. Department of Energy and U.S. Environmental Protection Agency requirements, this ENERGY STAR 2.0 UPS system provides high operational efficiency to signal a reduction in BTU emissions, save on utility and cooling costs and help protect the environment.

More from the Manufacturer

  • $250,000 Ultimate Lifetime Insurance
  • 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
  • 2-line front-panel LCD with 10 selectable screens reports detailed UPS and site power info
  • ENERGY STAR 2.0-certified to save electricity, lower costs and protect the environment
  • Unity power factor ensures maximum power possible at each power rating
  • Keeps equipment running during outages to allow time for file saves and safe shutdown
  • Protects equipment against blackouts, brownouts, transient surges and line noise

Additional information

Weight 50.7100 lbs
Dimensions 17.60 × 17.20 × 3.50 in
Battery Life

6 Year

Phase

Single Phase

Typical Battery Recharge Ti

4 Hour

EMI/RFI Noise Filter

Yes

Receptacle Type

NEMA 5-15R

Output Frequency

60 Hz

Maximum Operating Temperatu

104°F (40°C)

Battery Chemistry

Lead Acid

AVR

Yes

Replaceable Battery

Yes

Product Type

Line-interactive UPS

Input Frequency

60 Hz

Load Capacity (VA)

1440 VA

Application/Usage

Network Device,High-end System

Waveform Type

Sine Wave

Package Contents

<ul><li>SMART1500RMXL2U UPS System</li><li>PowerAlert software with USB and DB9 cables</li><li>Mounting hardware for 4 post rackmount installation</li><li>Cable for Emergency Power Off interface</li><li>Instruction manual with warranty information</li></ul>

Manufacturer Website Addres

https://tripplite.eaton.com/

USB

Yes

Product Line

SmartPro

Transfer Time

4 ms

Receptacle Detail

8 x NEMA 5-15R

Input Voltage

120 V AC

Rack Height

2U

Network Management

SNMP Manageable

Cord Length

10 ft

Plug/Connector Type

NEMA 5-15P

Form Factor

Rack/Tower

EPO Port

Yes

Limited Warranty

3 Year

Additional Warranty Informa

3 year with registration. Note: Registration is required for 3-year warranty.

Output Power Factor

1

Status Indicators

<li>UPS status (Solid Green)</li><li>Battery Mode (Solid Orange)</li><li>Battery Low Warning (Flashing Orange)</li><li>Fault/Alarm (Solid Red)</li>

Output Voltage

100 V AC,110 V AC,120 V AC,125 V AC

Alarm

UPS StartUp,Remote Shutdown,Overload,Low Battery,Power Failure

Load Capacity (Watt)

1440 W

Manufacturer

Tripp Lite by Eaton

Energy Saving

Greater than 95% efficiency – GREEN UPS; Individually controllable load banks

Sound Emission (A-Weighted)

40 dB(A)

DC System Voltage

48 V DC

Storage Temperature

5°F (-15°C) – 122°F (50°C)

Battery Characteristics

Valve-regulated

Backup/Run Time (Half Load)

15.10 Minute

Backup/Run Time (Full Load)

5.10 Minute

Hot Swappable

Yes

Country of Origin

China

UPC

0

MPN

SMART1500RMXL2U

Brand

Tripp Lite by Eaton
