Cisco B200 M5 UCSB-B200M5-RSV1D Blade Server – 2 x Intel Xeon 6254 3.10 GHz – 64 GB RAM – 240 GB SSD – (1 x 240GB) SSD Configuration – 12Gb/s SAS Controller
Login to View Prices
Delivering performance, versatility and density without compromise, the Cisco UCS B200 M5 Blade Server addresses the broadest set of workloads, from IT and web infrastructure through distributed database.
The enterprise-class Cisco UCS B200 M5 blade server extends the capabilities of Cisco’s Unified Computing System portfolio in a half-width blade form factor. The Cisco UCS B200 M5 harnesses the power of the latest Intel® Xeon® processor scalable family CPUs with up to 3072 GB of RAM (using 128 GB DIMMs), two solid-state drives (SSDs) or hard disk drives (HDDs), and up to 80 Gbps throughput connectivity.
The May 2019 update includes support for the following:
- 2nd Generation Intel® Xeon® Scalable Processors.
- 2933-MHz DDR4 memory DIMMs.
- 128 GB, 256 GB, 512 GB Intel® Persistent Memory Modules (PMEM).
- Up to 9 TB of memory is available if the memory slots are populated as follows:
- 12 x 256 GB DDR4 DIMMs
- 12 x 512 GB PMEMs
- Experience high performance, built-in security and remote management capabilities with Intel Xeon 3.10 GHz processor
- 3.10 GHz processor speed ensures optimal performance with fast and dependable results
- DDR4 SDRAM memory technology effectively enables data to be moved at various points in a CPU clock cycle to allow maximum productivity
- Octadeca-core (18 Core) processor core efficiently handles data to ensure quicker transfer of information with maximum usability
- 2 processors supported for faster, dependable performance and better access to data and information
- 2nd Gen server generation offer more threads, higher clocks, thus giving an optimal and faster system performance
- With 64 GB memory, improve system performance to execute complex applications
- RAID provides efficient data redundancy in the case of a drive failure to ensure maximum dependability
- 240 GB SSD provides you with enough space to store large files, digital content, documents and other data
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
Additional information
| Weight | 1.0000 lbs |
|---|---|
| Dimensions | 24.40 × 8.00 × 2.00 in |
| Error Checking | ECC |
| Memory Clock Speed | 2.93 GHz |
| Memory Technology | DDR4 SDRAM |
| Chipset Manufacturer | Intel |
| Controller Type | 12Gb/s SAS |
| Product Series | B200 M5 |
| Form Factor | Blade |
| Manufacturer Website Addres | |
| Manufacturer | Cisco Systems, Inc |
| Total Solid State Drive Cap | 240 GB |
| Number of Occupied Memory S | 12 |
| Solid State Drive Interface | M.2 |
| Graphics Controller Manufac | Matrox |
| Graphics Controller Model | G200e |
| Ethernet Technology | 10 Gigabit Ethernet |
| Network (RJ-45) | Yes |
| Processor Manufacturer | Intel |
| Processor Model | 6254 |
| Processor Speed | 3.10 GHz |
| Solid State Drive Configura | 1 x 240GB |
| Number of Solid State Drive | 1 |
| Operating System Supported | Windows Server 2019 Standard,Windows Server 2019 Datacenter,Red Hat Enterprise Linux,SuSE Linux Enterprise Server |
| Limited Warranty | 3 Year |
| Product Type | Server |
| Product Model | UCSB-B200M5-RSV1D |
| Number of Total Memory Slot | 24 |
| Processor Generation | 2nd Gen |
| Packaged Quantity | 1 |
| Number of Processors Suppor | 2 |
| Graphics Memory Capacity | 16 MB |
| RAID Supported | Yes |
| Chipset Model | C621 |
| Processor Type | Xeon |
| Maximum Memory Supported | 9 TB |
| Number of Processors Instal | 2 |
| Standard Memory | 64 GB |
| Processor Core | Octadeca-core (18 Core) |
| MPN | TR-B200M5-RSV1D |
| Brand | Cisco |
