APC by Schneider Electric Smart-UPS SRT 2200VA RM 120V
Login to View Prices
Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
- Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown
- Add up to 10 external battery packs (SRT72RMBP) for extended runtime
- Delivers clean power with zero transfer time for critical or sensitive devices
- Rack/Tower convertible (rail kit included)
- Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
- 2200VA/1800W double-conversion on-line pure sine wave 2U rackmount UPS
Additional information
| Weight | 55.0100 lbs |
|---|---|
| Dimensions | 23.00 × 17.00 × 3.30 in |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Software Included | Powerchute Serial Edition |
| Maximum Operating Temperatu | 104°F (40°C) |
| Battery Chemistry | Lead Acid |
| Replaceable Battery | Yes |
| Cord Length | 6 ft |
| Input Frequency | 70 Hz |
| Country of Origin | Philippines |
| Number of Battery & Surge O | 7 |
| Additional Warranty Informa | 3 years repair or replace (excluding battery) and 2 years for battery |
| Product Line | Smart-UPS |
| Waveform Type | Sine Wave |
| Typical Battery Recharge Ti | 3 Hour |
| Surge Energy Rating | 340 J |
| Storage Relative Humidity | 0% – 95% |
| Plug/Connector Type | NEMA 5-20P |
| Manufacturer | Schneider Electric SA |
| Manufacturer Website Addres | |
| Rack Height | 2U |
| Load Capacity (Watt) | 1800 W |
| Receptacle Type | NEMA 5-20P |
| Storage Temperature | -4°F (-20°C) – 122°F (50°C) |
| Battery Energy | 1101.6 kJ |
| Application/Usage | Server,Network Workstation |
| Status Indicators | LCD Display |
| Load Capacity (VA) | 2200 VA |
| Output Voltage | 120 V AC |
| DC System Voltage | 72 V DC |
| Maximum Operating Elevation | 10000 ft |
| Network Management | SmartSlot |
| Package Contents | <li>Smart-UPS SRT 2200VA RM 120V </li><li>CD with software</li><li>Documentation CD</li><li>Installation guide</li><li>Rack mounting brackets</li><li>Rack mounting hardware</li><li>Rack mounting support rails</li><li>USB cable</li><li>Warranty card</li> |
| Battery Life | 5 Year |
| Thermal Dissipation | 156.79 W |
| Maximum Storage Elevation | 50000 ft |
| Input Voltage | 120 V |
| EPO Port | Yes |
| Limited Warranty | 3 Year |
| Form Factor | Rack-mountable |
| Energy Star | Yes |
| Product Type | Double Conversion Online UPS |
| Environmental Certification | RoHS |
| Number of Batteries | 1 |
| Receptacle Detail | 1 x NEMA L5-20R,6 x NEMA 5-20R |
| Environmentally Friendly | Yes |
| Hot Swappable | Yes |
| Product Color | Black |
| UPC | 0 |
| MPN | SRT2200RMXLA |
| Brand | APC by Schneider Electric |
