StarTech.com HDMI over IP Extender with Video Compression – HDMI over CAT6 Extender – 1080p
Login to View Prices
Extend and control HDMI video over your existing LAN to create a state-of-the-art network of video displays in a variety of environments where digital signage is required.
Reliably Extend Compressed HDMI Video with Bandwidth Efficiency
This extender uses advanced compression to distribute high-quality HDMI video over your network, with minimal bandwidth requirements.
With advanced compression technology, broadcasting your video signal requires only 6 – 12 Mbps of local area network bandwidth, when in operation for each kit.
Flexible & Scalable Deployment Options
The HDMI over LAN extender offers many configurations to accommodate your set up.
This HDMI video extender provides four ways to control your video network configurations.
Comprehensive Product Testing & Expert Technical Support
StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to our customers. Our local StarTech.com Technical Advisors have broad product expertise and work directly with StarTech.com Engineers to provide support for our customers both pre and post-sales.
- Deliver brilliant HD quality video with 1080p support
- Newer Version Available: ST12MHDLAN2K features longer range (100m/330ft) and video wall support
- Easily create your ideal digital signage with a versatile and scalable video distribution system
- Efficiently distribute video throughout your site using your local area network
Additional information
| Transmitter Height | 1.10" |
|---|---|
| Graphics Modes | Full HD |
| Product Type | Video Extender Transmitter/Receiver |
| Connectivity Technology | Wired |
| Receiver Height | 1.10" |
| HDMI Out | Yes |
| Number of Network (RJ-45) P | 2 |
| Number of HDMI Outputs | 1 |
| Twisted Pair Cable Standard | Category 6 |
| Maximum Video Resolution | 1920 x 1080 |
| Number of Output Devices Su | 1 |
| HDMI In | Yes |
| Number of HDMI Inputs | 1 |
| Number of Input Devices Sup | 1 |
| Packaged Quantity Condition | Kit |
| Form Factor | Rack-mountable,Desktop |
| Media Type Supported | Twisted Pair |
| Network (RJ-45) | Yes |
| Receiver Width | 7" |
| Transmitter Width | 7" |
| Maximum Operating Distance | 164.04 ft |
| TAA Compliant | Yes |
| Country of Origin | Taiwan |
| Transmitter Depth | 12.20" |
| Transmitter Weight (Approxi | 7.05 lb |
| Limited Warranty | 2 Year |
| Package Contents | <ul> <li>1 x HDMI Over IP Transmitter</li> <li>1 x HDMI Over IP Receiver</li> <li>2 x Universal Power Adapters (NA, EU, UK, ANZ)</li> <li>2 x Mounting Brackets</li> <li>2 x CAT5 Cables</li> <li>1 x Plastic Screwdriver</li> <li>1 x IR Remote Control</li> <li>2 x USB-A to Mini USB-B Cable</li> <li>1 x DB9 to 2.5 mm Serial Adapter Cable</li> <li>1 x IR Blaster</li> <li>1 x IR Receiver</li> <li>8 x Rubber Feet</li> <li>1 x Instruction Manual</li> </ul> |
| Receiver Weight (Approximat | 7.05 lb |
| Receiver Depth | 12.20" |
| Manufacturer Website Addres | |
| Environmentally Friendly | Yes |
| Product Color | Black |
| Manufacturer | StarTech.com |
| UPC | 0065030878760 |
| MPN | ST12MHDLNHK |
| Brand | StarTech.com |
