StarTech.com HDMI Over CAT6 Extender – Power Over Cable – 4K 60Hz Up to 70m / 230 ft – 1080p 60Hz up to 100m / 328 ft
Login to View Prices
This HDMI Over CAT6 extendertransmitsyour HDMI audio/video signal to a remote location up to 100 m (328 ft.)away.
Get4K at 60Hz from 70 m (230 ft.)away
This HDMI over CAT6 extender maintains your Ultra HD 4K picture quality, even at 70 m (230 ft.)away from your video source. If you’re not running 4K video, this extender supports High-Definition 1080p 60Hz and lower resolutions at even greater distances, up to 100 m (328 ft.)from your HDMI source.
With full support for your HDMI 2.0 equipment, including4K resolution at 60Hz, this extender can transmit at a bandwidth of up to 18Gbps, making it the ideal solution for high-resolution tasks requiring the highest color detail. For smoother video and color transitions, the extender offers 4:4:4 chroma subsampling via visually lossless compression, meaning every pixel gets its own unique color.
Simplify your setup
The HDMI Extender Over CAT6 offers a hassle-free solution for your digital signage project. The extender only requires a single CAT5e or CAT6 cable, so you extend an HDMI signal using existing infrastructure that’s already in your building. Plus, this HDMI extender supports Power Over Cable (POC), which means you’ll only need one power adapter connected to either your transmitter or receiver. Mounting hardware is also included for discreet, professional installation.
The ST121HDBT20L is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support.
- Remotely control your video source from the location of your remote display, with support for IR extension
- Sleek professional installation with optional mounting hardware included
- Hassle-free setup with video and power over a single CAT5e or CAT6 cable
- Get astonishing video quality at impressive distances with UHD 4K 60Hz resolution at up to 70 m (230 ft.) and 1080p 60Hz resolutions at up to 100 m (328 ft.)
Additional information
| Product Type | Video Extender Transmitter/Receiver |
|---|---|
| Connectivity Technology | Wired |
| Maximum Operating Distance | 328.08 ft |
| HDMI Out | Yes |
| Number of Network (RJ-45) P | 2 |
| Maximum Video Resolution | 4096 x 2160 |
| Number of HDMI Outputs | 1 |
| Receiver Height | 1" |
| Twisted Pair Cable Standard | Category 6 |
| Number of Output Devices Su | 1 |
| Transmitter Depth | 4" |
| Receiver Weight (Approximat | 3.88 oz |
| Transmitter Weight (Approxi | 3.88 oz |
| HDMI In | Yes |
| Graphics Modes | 4K |
| Number of HDMI Inputs | 1 |
| Transmitter Height | 1" |
| Number of Input Devices Sup | 1 |
| Packaged Quantity Condition | Kit |
| Receiver Width | 3" |
| Transmitter Width | 3" |
| Package Contents | <ul> <li>1 x HDMI Over CAT6 Transmitter</li> <li>1 x HDMI Over CAT6 Receiver</li> <li>1 x Universal Power Adapter (NA/JP, EU, UK, ANZ)</li> <li>1 x IR Blaster</li> <li>1 x IR Receiver</li> <li>2 x Mounting Brackets</li> <li>8 x Rubber Feet</li> <li>1 x Quick-Start Guide</li> </ul> |
| Media Type Supported | Twisted Pair |
| Network (RJ-45) | Yes |
| Receiver Depth | 4" |
| TAA Compliant | Yes |
| Country of Origin | Taiwan |
| Limited Warranty | 2 Year |
| Manufacturer Website Addres | |
| Environmentally Friendly | Yes |
| Product Color | Black |
| Manufacturer | StarTech.com |
| UPC | 0065030877879 |
| MPN | ST121HDBT20L |
| Brand | StarTech.com |
