Startechcom Hdmi Kvm Extender Over Ip Network – 4k 30hz Hdmi and Usb Over Ip Lan or Cat5ecat6 Ethernet (100m330ft) – Remote Kvm Console

Login to View Prices

In stock

SKU: STCSV565HDIP Categories: , , , Brand:

StarTech.com HDMI KVM Extender over IP Network – 4K 30Hz HDMI and USB over IP LAN or Cat5e/Cat6 Ethernet (100m/330ft) – Remote KVM Console – HDMI KVM Extender over IP transmitter & receiver kit remotely controls KVM switch/console or PC from up to 330ft/100m over Cat5e/6 Ethernet network cable/IP enabled LAN – 4K UHD 30Hz /EDID Passthrough/USB2.0 HID/ Large Signage Display or Video Wall

Additional information

Brand

StarTech.com

Product Type

KVM Console/Extender

Environmentally Friendly

Yes

Environmental Certification

WEEE

Maximum Video Resolution

3840 x 2160

Graphic Mode

4K

Maximum Operating Distance

330 ft

USB

Yes

HDMI

Yes

Number Of HDMI Ports

2

Number Of Network (RJ 45) Por

2

Network (RJ 45)

Yes

Number Of USB Ports

5

Number Of Computers Supported

1

Number Of Remote Users Suppor

1

Transmitter Height

1.10"

Transmitter Width

4.60"

Transmitter Depth

5.10"

Receiver Height

1.10"

Receiver Width

4.60"

Receiver Depth

5.10"

Transmitter Weight (Approxima

1.34 lb

Receiver Weight (Approximate)

1.34 lb

TAA Compliant

Yes

Product Color

Black

Packaged Quantity Condition

Kit

Country Of Origin

Taiwan

Connectivity Technology

Wired

Brand Name

StarTech.com

Input Voltage Range

100V AC to 240V AC

Form Factor

Desktop

Manufacturer

StarTech.com

Product Name

HDMI KVM Extender over LAN – 4K 30Hz

Power Consumption

18 W

Input Voltage

240 V AC

Manufacturer Part Number

SV565HDIP

Manufacturer Website Address

http://www.startech.com

Marketing Information

<p>This HDMI KVM extender kit lets you use a keyboard, mouse and monitor to remotely control any computer over your IP-enabled local area network (LAN). Combined with a KVM switch, the KVM console extender can be used with multiple computers. The extender features four USB ports that enable you to connect other USB devices, in addition to your keyboard and mouse.</p> <p><b>Supports UHD 4K 30Hz</b></p> <p>The HDMI KVM extender delivers astonishing 4K UHD picture quality to your remote display with support for resolutions up to 3840 x 2160p at 30Hz.</p> <p><b>Hassle-Free Installation</b></p> <p>With a transmitter and a receiver, the KVM extender provides a complete end-to-end solution that supports mounting for tidy installation. Plus, it uses standard CAT5e or CAT6 Ethernet cable, eliminating the expense and hassle of specialized cables and enabling you to use existing network infrastructure.</p> <p>The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display over your LAN.</p> <p><b>Versatile Configuration Options</b></p> <p>The extender uses your local intranet to connect your computers to your remote workstation. You can connect additional receivers (sold separately) to distribute your HDMI signal to multiple displays in your remote location, or combine the source to create a video wall that expands your single video source across multiple displays.</p> <p>For smaller-scale applications, you can connect the transmitter and receiver units directly over CAT5 or CAT6 cabling up to 330 feet (100 meters).</p> <p>SV565HDIP is backed by a 2-year warranty and free lifetime technical support.</p> <p><a id="gfk-spex-minisite" rel="nofollow" href="javascript:void(0)" onclick="javascript:window.open('//content.etilize.com/mini-site/en_us/1059643393.html', '_blank', 'height=800, width=780, resizable=yes, scrollbars=yes, toolbar=no, menubar=no, location=no, directories=no, status=no'), return false, ">More from the Manufacturer</a></p>

Packaged Quantity

1

Package Contents

<ul> <li>1 x Transmitter Unit</li> <li>1 x Receiver Unit</li> <li>2 x Universal Power Adapters (NA, JP, EU, UK, AU/NZ)</li> <li>2 x Mounting Kits</li> <li>2 x Ethernet Cables</li> <li>2 x DB9 Serial Adapters</li> <li>2 x RJ11 Serial Cables</li> <li>1 x HDMI Cable (1.2 m)</li> <li>1 x USB Cable (1.5 m)</li> <li>8 x Rubber Feet</li> <li>1 x Plastic Screwdriver</li> <li>1 x Quick-Start Guide</li> </ul>

Limited Warranty

2 Year
